Input :
1x Component Video,
Digital Audio, S-Video,
Composite Video, Stereo Audio
Output :
8x Component Video,
Digital Audio, S-Video,
Composite Video,
Stereo Audio and 1x Loop Output Port
  • Introduction
  • Features
  • Specifications
  • SB-3790 is a high speed Video Bandwidth small signal 700MHz, large signal 380Mhz Distribution Amplifier product. It’s one of the most innovative Component Video(YPBPR), Digital Audio(PCM) and Stereo Audio(AR/AL) with Loop output function distribution amplifier product on the market Today. Support wall mount type. It has 1 individual input with 8 individual and 1 Loop Output outputs. Because it is a Component Video / Digital and Stereo Audio amplifier, The input may be distribution to any output; It completely eliminates the need to constantly move around Component Video, Digital Audio and Stereo Audio input and output cables. This distribution amplifier is ideally suited for full High Definition LCD HDTV Television for resolution 480p, 720p 1080i and 1080p or Plasma display monitor applications. Control is provided power switch via Front pushbuttons with LED readout. SB-3780 without Audio


  • 1. Support 1x input to 8x outputs and 1x Loop Output Distribution Amplifier
    2. Signals amplifier including : Component Video (YPbPr), Digital Audio (S/PDIF), Stereo Audio (AR/AL) signals
    3. Suitable for full HD high resolution Video player device and LCD/Plasma monitor displays. HDTV Resolution 480i, 480p, 576p, 720p
    4. Video Bandwidth : Small signal 1000MHz, (-3dB), Large signal 440MHz
    5. Digital Audio bandwidth : 110MHz. compatible Composite Video in/out
    6. Audio bandwidth : 60MHz. (-3dB)
    7. Audio Frequency Respond : 20Hz ~ 20KHz
    8. Low all hostile crosstalk of -83dB @ 5MHz
    9. Support one Loop Output port, Linkage connection the others 10 amplifier units
    10. Enclosure type : Support wall Rack mountable 1 inch high
    11. Support Lower power consumed full load under 800 mA
    12. Power supply offer a universal type 100~240 VAC switch
  • Type of amplifier 1 input to 8 outputs and 1x Loop Output Distribution Amplifier
    Type of Signals Component (YPbPr), Digital(S/PDIF), Stereo Audio signals
    Video Bandwidth Small signal 700MHz, (-3dB), Large signal 380MHz, R=380MHz,
    G=380MHz, B=380MHz, Digital=110MHz, Audio=60MHz
    Audio Bandwidth 60MHz, (-3dB)(Audio-Right=60MHz, Audio-Lift=60MHz)
    Audio Frequency Respond 20Hz ~20KHz
    All Hostile Crosstalk -84dB @ 5MHz, -54dB @ 50MHz
    Channel Crosstalk -56dB @ 100MHz
    Slew Rate 1000 V/us, G=+1,2 V Step
    Loop Output Support one extend port to the others 10 amplifier units
    Safety Approvals CE, FCC, VCCI
    Dimension (WxDxH) 9.06" x 4.49" x 1.06" (230mm x 114mm x 27mm)
    Weight 0.7 kg / 1.54 lb
    Power Voltage Input DC 12V @ 2A
